Ghosty reveal

I love it when photos do not just fade in. The good ones bleed in through a soft, cloudy edge, like the image is forming out of fog. It looks expensive and hard to build. It is neither.

The whole trick is a mask. A tall, feathered gradient is laid over the image, several times taller than the box, and you slide it across with mask-position. Because the edge of the mask is soft and a little cloudy, the image appears through a feathered front instead of a hard line. That is the ghost.

Below is the real thing on live images, with controls for how soft the bleed is, which way it travels, the duration and the easing. You can grab the component and the mask and drop them into anything.

Implementation

Direction
Easing

Code

"use client";

import {
  useEffect,
  useRef,
  useState,
  type CSSProperties,
  type ReactNode,
} from "react";

/**
 * GhostReveal — a soft "ghostly" image/element reveal.
 *
 * The trick: a tall, feathered alpha mask is laid over the element at
 * `mask-size: 100% <scale>%` (the mask is
 * several times taller than the box). Animating `mask-position` from one end to
 * the other slides that soft gradient across the element, so the content bleeds
 * in through a cloudy, feathered edge instead of a hard wipe — the ghost look.
 *
 * Direction just rotates which mask edge leads. Scroll-triggered by default via
 * IntersectionObserver; pass `play` to drive it yourself. Honors reduced motion.
 */

export type GhostDirection = "up" | "down" | "left" | "right";

export interface GhostRevealProps {
  children: ReactNode;
  /** Mask image — a soft feathered PNG with a VERTICAL ramp (for up/down). */
  maskSrc: string;
  /** Optional HORIZONTAL-ramp version of the mask, used for left/right so the
   *  feather runs along the wipe. Falls back to maskSrc if omitted (then
   *  left/right reveal without a horizontal feather). */
  maskSrcH?: string;
  /** How many times taller/wider than the box the mask is. Bigger = slower,
   *  softer bleed. Maps to `mask-size`. Default 500 (i.e. 500%). */
  scale?: number;
  /** Reveal duration in ms. Default 1000. */
  duration?: number;
  /** CSS easing. Default a gliding ease-out. */
  easing?: string;
  /** Which way the soft edge travels. Default "up" (rises from the bottom). */
  direction?: GhostDirection;
  /** Controlled trigger. When omitted, reveals on scroll-into-view (once). */
  play?: boolean;
  /** Visible fraction before the scroll trigger fires (0..1). Default 0.2. */
  threshold?: number;
  className?: string;
  style?: CSSProperties;
}

// The reveal is a soft gradient mask that slides across the box. The PNG asset
// is a vertical feather (good for up/down); for left/right we use a CSS gradient
// oriented horizontally so the feather runs along the wipe — NO element rotation
// (rotating a non-square box clips it). Each direction defines the mask image,
// its over-sized dimension, and the from/to positions for hidden→revealed.
function axisFor(
  dir: GhostDirection,
  maskSrc: string,
  maskSrcH: string,
  scale: number,
) {
  const pct = `${scale}%`;
  // Up/down use the vertical-ramp PNG (tall mask, sweeps along Y). Left/right use
  // the horizontal-ramp PNG (wide mask, sweeps along X). Both are REAL feathered
  // images and no element is rotated, so the feather is correct and nothing clips.
  switch (dir) {
    case "up": // feather rises from the bottom
      return { image: `url(${maskSrc})`, size: `100% ${pct}`, from: "0% 0%", to: "0% 100%" };
    case "down": // feather descends from the top
      return { image: `url(${maskSrc})`, size: `100% ${pct}`, from: "0% 100%", to: "0% 0%" };
    case "left": // feather sweeps in horizontally
      return { image: `url(${maskSrcH})`, size: `${pct} 100%`, from: "0% 0%", to: "100% 0%" };
    case "right":
      return { image: `url(${maskSrcH})`, size: `${pct} 100%`, from: "100% 0%", to: "0% 0%" };
  }
}

export function GhostReveal({
  children,
  maskSrc,
  maskSrcH,
  scale = 500,
  duration = 1000,
  easing = "cubic-bezier(0.16, 1, 0.3, 1)",
  direction = "up",
  play,
  threshold = 0.2,
  className = "",
  style,
}: GhostRevealProps) {
  const ref = useRef<HTMLDivElement>(null);
  const controlled = play !== undefined;
  const [shown, setShown] = useState(false);

  // Scroll trigger (uncontrolled mode). Fires once when the element scrolls in.
  useEffect(() => {
    if (controlled) return;
    const el = ref.current;
    if (!el) return;
    if (typeof IntersectionObserver === "undefined") {
      setShown(true);
      return;
    }
    const io = new IntersectionObserver(
      (entries) => {
        for (const e of entries) {
          if (e.isIntersecting) {
            setShown(true);
            io.disconnect();
          }
        }
      },
      { threshold },
    );
    io.observe(el);
    return () => io.disconnect();
  }, [controlled, threshold]);

  const open = controlled ? play! : shown;
  const { image, size, from, to } = axisFor(
    direction,
    maskSrc,
    maskSrcH ?? maskSrc,
    scale,
  );

  const reduce =
    typeof window !== "undefined" &&
    window.matchMedia?.("(prefers-reduced-motion: reduce)").matches;

  const maskStyle: CSSProperties = reduce
    ? { opacity: open ? 1 : 0, transition: `opacity 0.3s ${easing}` }
    : {
        WebkitMaskImage: image,
        maskImage: image,
        WebkitMaskSize: size,
        maskSize: size,
        WebkitMaskRepeat: "no-repeat",
        maskRepeat: "no-repeat",
        WebkitMaskPosition: open ? to : from,
        maskPosition: open ? to : from,
        transition: `-webkit-mask-position ${duration}ms ${easing}, mask-position ${duration}ms ${easing}`,
      };

  return (
    <div ref={ref} className={className} style={{ ...maskStyle, ...style }}>
      {children}
    </div>
  );
}
